ThinkRider Bike Chain 6 7 8 9 10 11 12 Speed Velocidade Electroplated Silver Bicycle Chain Mountain Road Bike MTB Chains Part 116 Links

Full electroplated chain for bicycle

Full electroplated bright silver / High tensile resistance / Rust and corrosion resistance / Wear resistance and durability Single Speed /6-7-8S/9S/10S/11S/12S

product information

Brand: ThinkRider Name: Bicycle chain Material: Carbon steel Color: Silver plating Length: Single speed 114 knots, 8-12 speed 116 knots Model: Single speed/Z80-6/7/8s, Z90-9s, Z10-10s, Z11-11s, RX 12-12s Speeds: Single speed/6-7-8/9/10/11 speed/12 speed(single speed/18s-21s-44s/27s/30s/33s/36s) Weight: 359g (single speed)/ 334g (Z80)/ 306g (Z90) / 315g (Z10)/287g (Z11)/ 278g (RX12) Suitable for: Road bikes, Mountain bikes, Folding bikes, etc Feature: Export quality, cost-effective, the use of full electroplating silver, rust and corrosion resistance, wear resistance and durability. Instead of the traditional ordinary color electroplating ordinary chain easy to rust, low tensile resistance. Accessories: Single speed (including magic button), 6-7-8S(press-in joint), 9S/10S/11S/12S(including magic button)

How do you tell which flywheel is which

How many rows of rear flywheels? How many speeds! As shown above, flywheel 8 row is 8 speed If your flywheel has 10 rows, it's 10 speed According to the flywheel speed to select the corresponding speed of the chain!

Strengthen the embedded axis

High rigidity reinforced structure, tight, flexible, not stuck, withstand high treading force

All plated bright silver

Quenching heat treatment, enhance wear resistance, wear resistance, surface rust treatment, lasting shining

Double X bridge chain

Enhance the tensile and torsional strength of the chain blade, speed change quickly and smoothly

Export quality fine workmanship

Single speed chain length 114 knots, 6-7-8/9/10/11 speed chain length 116 knots. Can use the chain cutter according to the length of their car needs to cut. Sectional stopper Need to purchase separately

6/7/8 Speed Chain

Specification: 1/2"x3/32" 116 section Color: three plating layers of silver anti rust Speed: 6/7/8/18/21/24 Shaft length: about 7.2mm Weight: about 334g(Z80) Magic clasp: press-in joint

Splice/Chain velcro

9 Speed Chain

Specification: 1/2"X11/128" 116 section Color: three plating layers of silver anti rust Speed: 9, 27 speed models Shaft length: about 6.6mm Weight: about 290g(Z90) Magic button: standard with a pair

Chain velcro

10 Speed Chain

Specification: 1/2" x 11/128" 116 section Color: three plating layers of silver anti rust Speed: 10, 20, 30 speed models Shaft length: about 6.1mm Weight: about 284g (Z10) Magic button: standard with a pair

Chain velcro

11 Speed Chain

Specification: 1/2" x 11/128" 116 section Color: three plating layers of silver anti rust Speed: 11, 33 speed models Shaft length: about 5.7mm Weight: about 254g (Z11) Magic button: standard with a pair

Chain velcro

12 Speed Chain

Specification: 1/2" X11/128" 116 section Color: three plating layers of silver anti rust Speed: 12, 36 speed models Shaft length: about 5.4mm Weight: about 278g(RX12) Magic button: standard with a pair

Chain velcro

Size

Note: The above data is manual measurement, there is a little deviation due to different tools and measurement methods.

Bicycle plated gold chain

Golden plating/high tensile resistance/rust and corrosion resistance/wear resistance and durability

product information

Brand: ThinkRider Name: Bicycle chain Material: Carbon steel Color: Gold Length: 116 knots Model: Z80(6/7/8S), Z90(9S), Z10(10S), Z11(11S) Speeds: 6-7-8 speed /9 speed /10 speed /11 speed (18S-21S-24s/275/30S/33S) Weight: 334g(Z80)/ 306g(Z90)/ 315g(Z10)/ 287g(Z11) Suitable for: The vast majority of mountain bikes, road cars, folding cars and so on. Feature: Export quality, cost-effective, using full electric gold plating, rust and corrosion prevention, wear resistant and durable. Accessories: Z80/Z90/Z10/Z11 (including a pair of magic buttons)

6/7/8 Speed Chain

Specification: 1/2 "x3/32" 116 section Color: gold plated anti rust Speed: 6/7/8/18/21/24 speed Shaft length: about 7.2mm Weight: about 334g(Z80) Magic button: standard with a pair

9 Speed Chain

Size: 1/2" x11/128 " 116 section Color: gold plated anti rust Speed: 9, 27 speed Shaft length: about 6.5 mm Weight: about 306g (Z90) Magic button: standard with a pair

10 Speed Chain

Specification: 1/2 "X11/128" 116 section Color: gold plated anti rust Speed: 10, 20, 30 speed Shaft length: about 6.3mm Weight: about 315g(Z10) Magic button: standard with a pair

11 Speed Chain

Specification: 1/2 "X11/128" 116 section Color: gold plated anti rust Speed: 11, 33 speed Shaft length: about 5.8mm Weight: about 287g(Z11) Magic button: standard with a pair

Magic buckle installation diagram

6/7/8S Chain install The original 8 speed chain is press-in joint without magic buckle STEP 1: Determine the length of the chain, and use a professional chain cutter to cut off the number of excess sections Step 2: On both ends, use a professional chain cutter to push back the chain shaft The connection point is displayed from multiple angles Use chain cutter to drive the chain axis clockwise

9S/10S Chain install

All three have magic clasp, with 9S as reference STEP 1: Determine the length of the chain, and use the chain cutter to cut off the number of excess sections Step 2: Put two pieces of magic buckle on both ends of the chain STEP 3: Wrap the ends of the magic buckle on each other's chain shafts STEP 4: After installing each other's chain axes, pull both sides with both hands to fix and install the magic buckle in place

Loading show

If there is a jump tooth after the new chain is changed, the main reasons are: 1: The new chain does not have a good bite with the flywheel tooth shape, so it needs to run in 2: The flywheel is severely worn. You are advised to replace it
