DF-96DK Automatic Water Level Controller Switch 20A 220V Water tank Liquid Level Detection Sensor Water Pump Controller 2m wires

taxnele. DF-96DK Automatic Water Level Controller Switch 20A220V Water tank Liquid Level Detection Sensor Water Pump Controller 2m wires. Parameter. Specification. Type: DF-96D Updated version. Working voltage: AC 220V/50HZ. Max Current: 10A(Use the 30A Delay). Installation: Din Rail Mount. Power consumption. 2W. transmission signal: 500M. Size: 1268851mm. Package include: 1pcs Automatic Water Level Controller Switch. 3pcs 200CM Sensor. Single-control UP pool water storage installation instructions shown in figure 1. A(red Upper water level control point. When water level gets to A point, the probe touch water and controller can stop the pump by auto. B(blue Lower water level control point. When water level gets off B point, the probe out of reach water and controller can start the pump by auto. C(black Should be placed in bottom of pool as the common line. D(green and E(yellow)are connected with C black). Single-control DOWN pool(drain water)installation instructions shown in figure
