Aideepen | AC/DC to DC Step-Down Power Module 15W AC85-265V to DC12V/24V Monitoring Switch Security Transformer for Electronic Components

Product Selling Points:1. It has a worldwide universal wide voltage input, which can be AC85 - 265V or DC120 - 374V, suitable for various power grid environments across the globe.2. Adopting a brand-new IC solution, with carefully selected materials, it provides stable voltage output, sufficient power, and sufficient current.3. It comes with overload, short-circuit, and over-temperature protection. It has stable performance and a long service life.4. Equipped with an EMI filter circuit, it has undergone full-load aging tests, and the input and output are isolated with high and low voltages.5. The PC flame-retardant plastic shell is moisture-proof and dust-proof. There are fixing screw mounting holes at two opposite corners, with a hole diameter of 3mm.Product Parameters:- AC Input: AC85 - 265V- DC Input: DC120 - 374V- Frequency Range: 47 - 63Hz- Surge Current: Cold start: 10A/220VAC- Leakage Current: - Standby Power Consumption: ≦150mV/230VAC- Output Voltage: 12V/24V (optional)- Rated Current: 1.2A/0.6A (optional)- Rated Power: 15W- Output Precision: ±1%- Voltage Regulation Rate: ±1%- Load Regulation Rate: ±1%Precautions:1. Before powering on, check whether the input and output leads are correct to avoid damaging the equipment and burning out the power supply.2. Before using the power supply, first confirm whether the input and output voltage specifications match the nominal values of the power supply to be used.3. The component pins on the bottom of the bare board power supply are conductive. Do not touch the bottom of the board when testing. Place an insulating rubber mat or clean paper, etc., non-conductive materials on the bottom of the board to avoid the risk of electric shock and burning out the power supply board.Packing List: Step-down module *1
