Az | RCXAZ 9g Plastic/Iron/Copper Gear 1.6KG Digital Servo for RC Fixed-Wing Airplane Robot Car Boat Duct Plane Small Servo Motor

RCXAZ 9g Plastic or Iron or Copper Gear 1.6KG/1.8KG Digital Servo for RC Fixed-Wing Airplane Robot Car Boat Duct Plane Small servo motorFeatures:High performance digital standardLow noise and long service lifSmall volume and large torqueSuit for RC car boat helicopter modelSpecifications:Item name: D1090PL / D1090Gu / D1090FeOperating Voltage : 4.8~6.0V DCMax. Torque : 4.8V≥1.20kgf·cm ； 6.0V≥1.60kgf·cmNo Load Speed : 4.8V≤0.14sec/60°; 6.0V≤0.12sec/60°Stall Current：4.8V≦680mA；6.0V≦780mAConsumption Current* (No Load)：4.8V ≦130mA ；6.0V≦150mAMax. Operating Travel Angle：180°±10°(500~2500μs）Dead Band Width: ≤ 3usMechanical Limit Angle: 180°Communication Interface: PWMMotor Type: Coreless motorCase Material: ABSGear Set Material : Plastic / Iron / Copper GearWeight: 9gSize: 32.5 × 12.1 × 32mmLength of Connector cable: JR 200±5mm (exposed without plug)Package included:1 * 9G Digital Servo1 * Servo Arm Accessories
