36V 1000W Ebike Brushless DC motor 2-mode Controller With LockPower LED display Speed Rotary Throttle For Electric Scooter Bike

36V 1000W controller can work with hall connect sensor or not connect hall sensorRated Voltage: 36VLow Voltage : 31V/42V/52V±0.5V/Rated Power: 1000WLimit Current:30A1.self-learning2. cruise line3. reverse line4. high brake5. low brake6.3-speed (low/middle/high)7.throttle8. electric lock9. hall line10. LCD instrument line11. Anti-theft power supply12. Anti-theft signal13. battery (red battery+, black battery-)14.motor15. pointer meter line1. connect the motor line (color to color，if motor without hall line, don't need connect hall line）2. connect the battery line(red:battery + , black:battery-)3. connect the controller throttle line to throttle, controller electric lock connect to throttle electric lock（if throttle not have electric lock,the electric lock 2 wires of the controller can be docked together）4. docking the two self-learning lines, the wheel will forward or reverse.(1. if wheel forward ,Separate the self-learning line. 2. if wheel reverse, Separate the self-learning line.  Docking the self-learning line again，if wheel forward ,Separate the self-learning line.) Self-learning is to adapt to the supply voltage5. other functions can be connected as needed.Throttle:■ Size: (Lx D) 10 cm x 2 cm / 3.■ Throttle Works Voltage: DC5V■ Speed Adjusting Signal:0.8V～4.3V■ Power display Voltage: DC 36V/1000W■ Power display:■ Normal: 23V above, 3 Led Green,■ Half: 23V ~ 20V, Led Yellow,■ Empty: 20V or less, Led Red■ Rotation angle: 0 °~ 70 °■ Working temperature: -20 ℃~ +50 ℃■ Fits standard 7/8 inches(22.2mm) handle bars■ Cable length is approximately 59 inches (1.5m)■ Quantity: 2 pcs (1 Twist throttle grip and 1 normal grip (matching thumb grip) )■ Electric Bike scooter twist throttle accelerator with power display, 5 led battery indicator.
