Thru Axle12mm for Road Bike Shaft Front/Rear Hub Skewers Front Fork Shaft Skewers12x142mm 12x100mm Wheel Axis Hub Shaft NEW

Ultralight Thru Axle Skwer for Road Bikes*Please choose the size you need to buy to avoid buying the wrong sizeBrand: ONIRIIMaterial: aluminum alloy 7075 Torque: 9-13.5N.mRod diameter:12mmThread length:17mmThread pitch:1.5mmTotal length of wheel skewer: (front) 120mm, (rear) 169mmRemoval tool : M6 hexagon socket toolSpecification：front wheel 12x100 mm , rear wheel 12x142 mmWeight: single front, 26g, single rear, 35gHow to choose the right specification?Quickly know the size of the front and rear wheel, and correctly select the specification of the thru-axleMeasure the front wheel as follows① Fork inside measurement② Fork outside measurement③ Thread pitchdimension measurementMeasure the rear wheel as follows① Frame inside measurement② Frame outside measurement③ Thread pitchdimension measurementThru-axle skewer dimensions:Thread pitch measurement method：Installation and removal with 6MM hexagonal wrenchNeed to know before buying:1, our thru axle skewer marked with specifications parameters, please select the appropriate specifications for your bike 2, the correct specification should be measured according to the specific length of the fork and frame required thru axle, choose the corresponding length of the thru axle skewer: our thru axle skewer marked 120mm and 169mm refers to the total length3, the thread pitch is 1.5 (please purchase according to your own needs of thread pitch and length specifications)4, if our specifications do not apply to your frame, you can purchase spacers to adjust it5, after receiving the thru axle rod is recommended not to install but to put on the frame to measure whether it is suitable, once the lubricant is applied and installed after the return is not supported!
