LED Dimmer 220V 230V Wireless Remote Control AC Triac RF Switch Push Dimmer 2.4G Touch Dimer for LED Lamp Bulb Light MJJC-S1-B

AC Triac RF + Push DimmerModel No.: S1-BFeatures：● RF + Push AC phase-cut dimmer, 1 channel output. ● To dim and switch single color dimmable LED lamps, traditional incandescent and halogen lights. ● 256 levels 0-100% dimming smoothly without any flash. ● Leading edge dimming or trailing edge dimming set by dip switch. ● Min brightness can be set by key. ● Compatibility with RF 2.4G single zone or multiple zone dimming remote control. ● Connect with external push switch to achieve on/off and 0-100% dimming function. ● Easy to be placed in standard wall junction box behind a push switch. ● Over-heat / Over-load protection, recover automatically.Caution:Please carefully ensure all wire connections and polarities are correct and secure before applying power, otherwise this controller will be damaged.Push Dim Function:You can also add a push switch to realize dimming.● Short press: Turn on or off light.● Long press (1-6s): Press and hold to step-less dimming, With every other long press, the light level goes to the opposite direction.● Dimming memory: Light returns to the previous dimming level when switched off and on again, even at power failure.Note:When calculating the maximum number of load lamps or drivers, the input power or input current parameters of a single lamp or driver must be used, the output power parameters can not be used. In addition, the maximum surge current of the dimmer is 65A, the sum of surge current of multiple dimmable LED drivers should not exceed 2 times. otherwise, the product will be overloaded and damaged.Min brightness settingLong press Min set key for 2s, the light blink 2 times, ready for min brightness set, Then short press Min set key 1-6 times, to get 6 min brightness: 5%, 10%, 15%, 20%, 25% or 30%, The light will output the current min brightness immediately, Long press Min set key for 2s or wait 8s, quit min brightness set, the light will output 100% brightness automaticallyMatch Remote Control (two match ways)End user can choose the suitable match/delete ways. Two options are offered for selection:Use the controller’s Match key● Match: Short press match key, immediately press on/off key (single zone remote) or zone key (multiple zone remote) of the remote。 ● Delete: Press and hold match key for 5s to delete all match, The light blinks 5 times means all matched remotes were deletedUse Power Restart● Match: Switch off the power, then switch on power again, immediately short press on/off key (single zone remote)or zone key (multiple zone remote) 3 times on the remote. The light blinks 3 times means match is successful. ● Delete: Switch off the power, then switch on power again, immediately short press on/off key (single zone remote) or zone key (multiple zone remote) 5 times on the remote. The light blinks 5 times means all matched remotes were deleted.
