[PERNG] Tehe 10S 36V 15A BMS Split Ports With Temperature Control For Scooter Lithium 18650 Battery Pack

Charging protection: Overcharge protection voltage single cell): 4.2V(Min)4.25V(Typ)4.3(Max). Overcharge release voltage single cell): 4.1V(Min)4.15V(Typ)4.2(Max). Charge overcurrent protection delay time: 500ms(Min)1000ms(Typ)1500ms(Max). Discharge protection: Over-discharge protection voltage single cell): 2.6V Min 2.7V Typ 2.8 Max). Overcharge release voltage single cell): 2.9V(Min)3V(Typ)3.1V(Max). Overcharge delay time: 3000ms(Min)4700ms(Typ)6400ms(Max). Short circuit protection: Short circuit protection delay time: 200ms(Min)350ms(Typ)550ms(Max). Short-circuit protection release condition: unplug the load. Self-consumption power: 30uA(MAX). Protection board conduction internal resistance: 25m MAX). Operating temperature range: 20°C Min 70°C Max). Dropped wire protection: When a battery string is welded with missing or dropped wires. The circuit will be disconnected for protection. Remarks: The internal resistance of the protection board and self-consumption are dynamic values. Du
