438178 ZXC BTS7960 43A Double H-bridge High-Power Driver Module DIY Smart Car Current Diagnostic For Arduino

BTS7960B H-bridge 43A high-power motor driver Module Overview: This driver uses chips BTS7960 composed of high-power drive full H-bridge driver module with thermal over-current protection. Double BTS7960 H-bridge driver circuit, with a strong drive and braking, effectively isolating the microcontroller and motor driver High-current 43A. Features: Double BTS7960 large current 43 A H bridge driver, 5V isolate with MCU, and effectively protect MCU, 5V power indicator on board, Voltage indication of motor driver output end, can solder heat sink, PIN. Definition: 1. RPWM: Right Turn PWM. 2. LPWM: Left Turn PWM. 3. R_EN: Right Turn Enable High Active). 4. L_EN: Left Turn Enable High Active). 5. R_IS: Right Turn Current Warning May Leave Floating). 6. L_IS: Left Turn Current Warning May Leave Floating). 7. VCC: 5V). 8. GND. aeProduct. getSubject. Connections: Method 1: VCC: 5V from Microcontroller(MCU). GND: GND from Microcontroller(MCU). L_PWM: PWM or 5V from Microcontroller(MCU for CCW(CW T
