Aideepen | 10A 30A Ideal Diode Module Anti-backflow Anti-reverse Ultra-low Power Simulation Mini Rectifier Board 60V 100V

Features:1. Wide voltage operation, suitable for diverse industrial power scenarios with high compatibility to meet varying load demands2. Ideal diode control circuit effectively prevents reverse current flow and backflow, safeguarding power system integrity3. Ultra-low conduction power consumption significantly reduces voltage drop and heat generation, enhancing overall energy efficiency4. Miniature compact design with small footprint, facilitating integration into space-constrained industrial modules5. High reliability and stability, engineered for industrial environments with long-term operational stabilityProduct Specifications60V10AMaximum 60V withstand voltageOperating range: 0.6-55VThis ideal diode module employs a dedicated chip to simulate an ideal diode rectifier. Two 6mR low-resistance MOSFETs are connected in parallel, minimizing voltage drop during high-current operation and eliminating the 0.7V voltage drop typical of standard diodes. Tested air-cooled operation supports up to 16A. When mounted on a large heat sink, theoretical operation exceeds 30A depending on thermal conditions. Ensure module temperature does not exceed 110°C, otherwise rapid overheating will occur.100V 60AMaximum 100V withstand voltageOperating range: 5-100VThis ideal diode module employs a dedicated chip to simulate an ideal diode rectifier. It utilizes two 0.8mΩ low-resistance MOSFETs in parallel, minimizing voltage drop during high-current operation and avoiding the 0.7V high voltage drop typical of standard diodes. Tested under air-cooled conditions, it can handle 40A. When mounted on a large heat sink, the module can theoretically handle over 60A depending on heat dissipation. The module requires a ground connection, offering superior noise immunity and broader application range compared to ungrounded ideal diodes, while also providing more stable output.Package ContentsIdeal Diode Module*1
