Intel | Intel Xeon E3 1225V3 E3 1225 V3 32 GHz Used Quad-Core Quad-Thread CPU 8M 84W LGA 1150

The Intel Xeon E3-1225 v3 and the E3 1220V3 that you previously learned about belong to the E3 v3 series launched in the second quarter of 2013. The core architecture is the same, but its biggest highlight is the integration of core graphics cards. Other parameters have also been slightly adjusted, making it more suitable for entry-level servers or office devices that do not require a dedicated graphics card. The following are its detailed parameters and features:Core and main frequencyAlso designed with 4 cores and 4 threads, it does not support hyper threading technology. The basic frequency has been increased to 3.2GHz, and the maximum frequency can reach 3.6GHz after the turbo acceleration 2.0 is turned on. Compared with the 3.1GHz main frequency and 3.5GHz turbo frequency of E3 1220V3, the computing performance has been slightly improved; The cache capacity maintains 8MB intelligent cache, ensuring efficient data reading and meeting the needs of basic server computing and daily office multitasking.Process and power consumptionContinuing the 22 nanometer Haswell architecture process, the thermal design power consumption (TDP) has been slightly increased from 80W for E3 1220V3 to 84W, with a small increase in power consumption. It can be stably cooled with a conventional tower heat sink and is suitable for compact server or desktop computer cases.Memory and InterfaceThe memory specifications and interfaces are completely consistent with E3 1220V3. Supports DDR3 and DDR3L 1333/1600MHz memory, with a maximum capacity of 32GB, and is compatible with ECC memory to ensure stable server data transmission; The interface is LGA1150, which can be paired with consumer grade motherboards such as B85 and H87 to reduce installation costs.Nuclear Display and Expansion TechnologyThis is the core difference between it and E3 1220V3, as it integrates a core graphics card. The core display has a basic frequency of 350MHz and a maximum dynamic frequency of 1.2GHz. It supports technologies such as Intel Fast Sync Video and Clear Video HD, and can connect up to 3 monitors without the need for a separate graphics card to meet office display and basic audio and video playback needs. In terms of expansion, it also supports PCIe 3.0 specification and 16 PCIe channels, and has VT-x/VT-d virtualization, AES encryption instructions, Borui technology, etc., balancing expansion capability, data security, and remote management requirements.Intel Xeon E3-1225 v3 specificationsGeneral informationTypeCPU / MicroprocessorMarket segmentServerFamilyIntel Xeon E3-1200 v3 Model number E3-1225 v3CPU part numbersCM8064601466507 is a tray processor with Hyper-Threading technologyCM8064601466510 is a tray processor without Hyper-Threading technologyBX80646E31225V3 is a boxed microprocessorFrequency3200 MHzMaximum turbo frequency3600 MHz (1 core)3400 MHz (4 cores)Bus speed5 GT/s DMIPackage1150-land Flip-Chip Land Grid ArraySocketSocket 1150 / H3 / LGA1150Size1.48" x 1.48" / 3.75cm x 3.75cmIntroduction dateJune 2, 2013 (launch)June 4, 2013 (announcement)End-of-Life dateLast order date for consumer processors is June 26, 2015Last shipment date for consumer tray processors is June 3, 2016S-spec numbersPart numberES/QS processorsProduction processorsQE6CQEHTSR14USR1KXBX80646E31225V3++CM8064601466507+++CM8064601466510+Architecture / MicroarchitectureMicroarchitectureHaswellPlatformDenlow Processor core Haswell LGA1150 Core stepping C0 (QE6C, QEHT, SR14U, SR1KX)Manufacturing process0.022 micronData width64 bitThe number of CPU cores4The number of threads4Floating Point UnitIntegrated Level 1 cache size 4 x 32 KB 8-way set associative instruction caches4 x 32 KB 8-way set associative data cachesLevel 2 cache size4 x 256 KB 8-way set associative cachesLevel 3 cache size8 MB 16-way set associative shared cachePhysical memory32 GBMultiprocessingUniprocessorExtensions and TechnologiesMMX instructionsSSE / Streaming SIMD ExtensionsSSE2 / Streaming SIMD Extensions 2SSE3 / Streaming SIMD Extensions 3SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 AES / Advanced Encryption Standard instructionsAVX / Advanced Vector ExtensionsAVX2 / Advanced Vector Extensions 2.0BMI / BMI1 + BMI2 / Bit Manipulation instructionsF16C / 16-bit Floating-Point conversion instructionsFMA3 / 3-operand Fused Multiply-Add instructionsTSX / Transactional Synchronization Extensions EM64T / Extended Memory 64 technology / Intel 64  NX / XD / Execute disable bit  TBT 2.0 / Turbo Boost technology 2.0  VT-x / Virtualization technology VT-d / Virtualization for directed I/OTXT / Trusted Execution technologyLow power featuresCore C1/C1E, C3 and C6 statesPackage C1/C1E, C3 and C6 states Enhanced SpeedStep technology Integrated peripherals / componentsIntegrated graphicsGPU Type: HD P4600Graphics tier: GT2Microarchitecture: Gen 7.5Execution units: 20Base frequency (MHz): 350Maximum frequency (MHz): 1200The number of supported displays: 3Memory controllerThe number of controllers: 1Memory channels: 2Supported memory: DDR3-1333, DDR3-1600DIMMs per channel: up to 2Maximum memory bandwidth (GB/s): 25.6ECC supported: YesOther peripheralsDirect Media Interface 2.0PCI Express 3.0 interfaceElectrical / Thermal parametersThermal Design Power84 Watt
