Intel i5 3570 Core i5-3570 3.4 GHz Used CPU

Intel Core i5-3570 is a mid-range desktop CPU in Intel's third-generation Core processor (Ivy Bridge architecture), released in 2012. With balanced performance and stability, it has been widely used in mainstream desktop platforms. Here is its detailed information:1、 Core parametersArchitecture and process: Based on the 22nm Ivy Bridge architecture, compared to the previous generation Sandy Bridge architecture, there is a certain improvement in energy efficiency and integrated graphics card performance.Core and Threads: 4 cores and 4 threads (does not support hyper threading technology).Frequency: The base frequency is 3.4GHz, and the maximum turbo frequency is 3.8GHz (turbo technology only automatically increases the single core or multi-core frequency when the load is high).Cache: 6MB of third level cache (L3 cache is shared by all cores to improve data access efficiency).2、 Interface compatible with motherboardSlot type: LGA 1155 interface, compatible with motherboards that support LGA 1155 slots. Common compatible chipsets include Z77, H77, B75, etc. (note that some early H61 motherboards may require BIOS support).3、 Memory supportSupports DDR3 memory with a maximum memory frequency of 1600MHz (some motherboards can support higher frequencies through overclocking).Number of memory channels: Dual channels, maximum supported memory capacity 32GB (single channel maximum 16GB, depending on motherboard support).Does not support ECC memory (mainly for the consumer market).4、 Integrated graphics cardIntegrated Intel HD Graphics 2500 core display, with a base frequency of 650MHz and a maximum dynamic frequency of 1100MHz.Supports DirectX 11 and OpenGL 4.0, which can meet light needs such as daily office work, web browsing, and 720P/1080P video playback, but is not suitable for large games.Supports dual screen output (such as HDMI, VGA, DVI, etc., depending on the motherboard design).5、 Power consumption and heat dissipationThe thermal design power consumption (TDP) is 77W, and the power control is relatively balanced. Paired with a hundred yuan air-cooled radiator (such as Xuanbing 300), it can operate stably without the need for high-end cooling solutions.Intel Core i5-3570 specifications General informationTypeCPU / MicroprocessorMarket segmentDesktopFamilyIntel Core i5Model number?i5-3570CPU part numbersCM8063701093103is an OEM/tray microprocessorBX80637I53570is a boxed processor with fan and heatsink (English version)BXC80637I53570is a boxed processor with fan and heatsink (Chinese version)Frequency?3400 MHzMaximum turbo frequency3800 MHz (1 or 2 cores)3700 MHz (3 cores)3600 MHz (4 cores)Low power frequency1600 MHzBus speed?5 GT/s DMIClock multiplier?34Package1155-land Flip-Chip Land Grid ArraySocketSocket 1155 / H2 / LGA1155Size1.48" x 1.48" / 3.75cm x 3.75cmIntroduction dateJune 3, 2012End-of-Life dateLast order date is December 26, 2014Last shipment date is June 5, 2015S-spec numbersPart numberES/QS processorsProduction processorsQCBTSR0T7BX80637I53570+BXC80637I53570+CM8063701093103++Architecture / MicroarchitectureMicroarchitectureIvy BridgeProcessor core?Ivy BridgeCore stepping?N0 (QCBT, SR0T7)Manufacturing process0.022 micronData width64 bitThe number of CPU cores4The number of threads4Floating Point UnitIntegratedLevel 1 cache size?4 x 32 KB 8-way set associative instruction caches4 x 32 KB 8-way set associative data cachesLevel 2 cache size?4 x 256 KB 8-way set associative cachesLevel 3 cache size6 MB 12-way set associative shared cachePhysical memory32 GBMultiprocessingUniprocessorFeaturesMMX instructionsSSE / Streaming SIMD ExtensionsSSE2 / Streaming SIMD Extensions 2SSE3 / Streaming SIMD Extensions 3SSSE3 / Supplemental Streaming SIMD Extensions 3SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4?AES / Advanced Encryption Standard instructionsAVX / Advanced Vector ExtensionsF16C / 16-bit Floating-Point conversion instructionsEM64T / Extended Memory 64 technology / Intel 64?NX / XD / Execute disable bit?TBT 2.0 / Turbo Boost technology 2.0?VT-x / Virtualization technology?VT-d / Virtualization for directed I/OTXT / Trusted Execution technologyLow power featuresEnhanced SpeedStep technology?Integrated peripherals / componentsIntegrated graphicsGPU Type: HD 2500Microarchitecture: Gen 7Execution units: 6Base frequency (MHz): 650Maximum frequency (MHz): 1150The number of supported displays: 3Memory controllerThe number of controllers: 1Memory channels: 2Supported memory: DDR3-1333, DDR3-1600Maximum memory bandwidth (GB/s): 25.6Other peripheralsDirect Media Interface 2.0PCI Express 3.0 interfaceElectrical / Thermal parametersMaximum operating temperature?67.4°C (case)105°C (junction)Thermal Design Power?77 Watt
