1 Pair Gigabit 100/1000M A/B SC Ethernet Fiber Switch Media Converter Rj45 Optic Transceiver 20KM fibra Switch

please note:Default with 1pcs 1310nm A side Fiber module and 1pcs 1550nmB side 10/100/1000M SFP slot Mini ethernet fiber media converter PCBA board 10/100/1000Base-TX to 1000Base-X high performance Realtek media converter IC chip (FMC-GE8213-MIN)GE-MIN media Converter complies with IEEE802.3z, IEEE802.3ab Standards It is designed to convert data signal between 10/100/1000 Base-Tx and 1000Base-X Gigabit Ethernet.It supports 10/100/1000Base-Tx and 1000Base-X applications. The data signal converted by such high performance media converter can be transmitted up to 100km maximum by single-mode 9/125um fiber-optical cable from RJ45 Cooper Cat.5 network cable (depend on optical module).The Converter has 1x fiber port, 1x RJ45 jacks and one power supply receptacle. Six LED indicators are built-in for easy diagnosing and monitoring the status of power(PWR), Unshielded Twisted Paired Link/ UTP Activity(TP/ACT), Fiber Link/ Fiber Activity(FX/ACT), Full/Half duplex (FDX) and data rates(1000M) and (100M). It can be configured automatically for Full Duplex or Half Duplex operation.It is compact, cost-effective, low dissipative, high reliable and stable. it is 5VDC input.Features:◆ Support the IEEE802.3 fast Ethernet standard (10Mbps)◆ Support the IEEE802.3u Fast Ethernet standard(100Mbps)◆ Support the IEEE802.3ab and IEEE802.3z Gigabit Ethernet standard (1000Mbps)◆ Support the IEEE802.3x full-duplexes flow control◆ Support install 1.25Gb/s SFP, CWDM SFP, DWDM SFP, WDM bi-di SFP◆ Full-duplexes, half-duplex auto negotiation◆ 10M/100M/1000M bit rate auto negotiation◆ 5VDC input.◆ Automatic identification of MDI/MDI-X cross line.◆ Max.9000 bytes packet at cut-through mode, Max.2046bytes packet at store-and-forward mode.◆ low power consumption low heat, standalone type with special communication power supply.◆ Support LFP function.◆ Very lower BER rate, <1/1000000000◆ Time Delay:Store-and-forward mode:9.6us,Cut-through mode: 0.9us◆ Life time>100,000 hours◆ In conformity to safety code of FCC, CE certification.
