JFIND JF327 Pro OBD2 Scanner Bluetooth 5.1 PIC18F25K80 Chip For IOS/Android ELM327 Code Reader OBDII Diagnostic Tool Free Update

JFIND JF327 Pro OBD2 Scanner Bluetooth 5.1 PIC18F25K80 Chip For iOS/Android ELM327 Code Reader OBDII Diagnostic Tool Free UpdateSpecificationModel name: JFIND JF327 ProCommunication method: Bluetooth 5.1Chip: PIC18F25K80Working voltage: DC 9V~16VWorking current: 40mA~60mAOperating environment: -20~60 ℃Storage temperature: -20~60 ℃Supported systems: For iOS , For AndroidSupport 16 LanguageEnglish/Spanish/Russian/German/French/Japanese/Chinese/Italian/Korean/Portuguese/Malay/Thai/Filipino/Vietnamese/Polish/DutchProtocols supported by OBDII1. SAE J1850 PWM (41.6 Kbaud)2. SAE J1850 VPW (10.4 Kbaud)3. ISO 9141-2 (5 baud init,10.4 Kbaud)4. ISO 14230-4 KWP (5 baud init,10.4 Kbaud)5. ISO 14230-4 KWP (fast init, 10.4 Kbaud)6. ISO 15765-4 CAN (11bit ID,500 Kbaud)7. ISO 15765-4 CAN (29bit ID,500 Kbaud)8. ISO 15765-4 CAN (11bit ID,250 Kbaud)9. ISO 15765-4 CAN (29bit ID,250 Kbaud)Design ConceptJFIND OBD Exclusive Software Fully Automatic Connection SuccessfulStep 1: Install the productStep 2: Turn on Bluetooth on you phoneStep 3: Open the app to automatically connectProduct FeaturesDiagnosis of Automotive Engine MalfunctionsClear the malfunction light of the car engineCar freeze frameMIL statusVehicle information readingReal time data streamVoltage reading of car batteryMode 6 detectionOxygen sensor testingMode 8 TestFault code inquiryDashboardTravel analysisPerformance testingBuilt in 35901 fault code libraryMonitoring and testingSupported vehicle dataRead error diagnostic codesClear fault codes (clear error codes and turn off MIL)Engine RPM (revolutions per minute)Calculated load valueCoolant temperatureFuel system statusSpeedShort term fuel situationLong term fuel situationManifold pressure Fuel injection advance timeIntake air temperatureAirflow velocityAbsolute position of throttle valveOxygen detection voltage associated with short-term fuel stateFuel system statusFuel pressureFuel consumption monitoring, etcNote: The number of supported data items varies depending on the model year, and the actual support situation shall prevail.Package Included1 x Car OBD II Scanner1 x User Manual
