diymore | Ideal Diode Module 100V/30A 60V/10A Anti-Backflow Rectifier Board Ultra-Low Power Industrial Power Protection

Features1. Wide voltage operation suitable for diverse industrial power applications with high compatibility to meet varied load requirements2. Ideal diode control circuit effectively prevents current backflow and reverse current, safeguarding power system integrity3. Ultra-low conduction power consumption significantly reduces voltage drop and heat generation, enhancing overall energy efficiency4. Miniature compact design with small footprint facilitates integration into space-constrained industrial modules5. High reliability and stability engineered for industrial environments, ensuring long-term operational stabilityParameter60V10AMaximum 60V withstand voltageOperating range: 0.6-55VThis ideal diode module employs a dedicated chip to simulate an ideal diode rectifier. Two MOSFETs with 6mR low internal resistance are connected in parallel, minimizing voltage drop during high-current operation and eliminating the 0.7V voltage drop typical of standard diodes. Tested at 16A under air cooling. When mounted on a large heat sink, theoretical operation exceeds 30A depending on thermal conditions. Ensure module temperature does not exceed 110°C, otherwise rapid overheating will occur.100V 60AMaximum 100V withstand voltageOperating range: 5-100VThis ideal diode module employs a dedicated chip to simulate an ideal diode rectifier. It utilizes two 0.8mΩ low-resistance MOSFETs in parallel, minimizing voltage drop during high-current operation and avoiding the 0.7V voltage drop typical of standard diodes. Tested under air-cooled conditions, it can handle 40A. When mounted on a large heat sink, the module can theoretically handle over 60A depending on heat dissipation. The module requires a ground connection, offering superior noise immunity and broader application range compared to ungrounded ideal diodes, with more stable output.Package includeIdeal Diode Module*1
