High-Precision XR2206 Signal Generator Kit - 1Hz to 1MHz Adjustable Frequency Sine/Triangular/Square Wave Output (DIY Build)

Tips: The purchased XR2206 is a piece that requires the buyer to splice another finished productXR2206 High precision signal generatorCircuit characteristics:• Can produce sine wave, triangular wave, square wave• Frequency can be from 1HZ-1MHZ• Frequency, amplitude adjustable;• five-bit precision resolution;• Frequency adjustment has coarse adjustment and fine adjustment;• Wide range of power supply, can use external power 9-12V or 9V battery;• All in-line components, small number of components, simple installation and debugging.Parameters: Technical specifications:Power supply voltage: 9-12V DC inputWaveform: square, sine and triangleImpedance: 600 ohms + 10%Frequency: 1hz-1mhzSinusoidal waveAmplitude: 0-3V at 9V DC inputDistortion: less than 1% (1kHz)Flatness: + 0.05db 1hz expansionSquare waveAmplitude: 8v (no load) at 9V DC inputRise time: less than 50ns (1kHz)Drop time: less than 30ns (1kHz)Symmetry: less than 5% (1kHz)Triangular waveAmplitude: 0-3V at 9V DC inputLinearity: less than 1% (up to 100kHz) 10ma                                                        PRODUCT DISPLAY
