Aideepen | PWM Pulse Signal Source Simulator Current Voltage Signal Generators 0-10V 4-20mA Measuring Range ±50V ±50mA with Analog Input

Features:1. Triple power supply options: 24V terminal/USB-C/built-in lithium battery, flexibly adapting to various work scenarios2. High-frequency PWM output: 1-150kHz frequency + 0-100% duty cycle, meeting motor speed control requirements3. Professional-grade HMI: 2-inch TFT color display with switchable Chinese/English interface for clear information at a glance4. Precise and convenient adjustment: EC11 digital encoder with large knob and electroplated keycaps for excellent tactile feedback5. Deeply tailored for industrial environments: Specially designed for industrial control signal debugging and PWM motor speed regulation across multiple scenariosParameter:Product Name: Multifunctional PWM Pulse Signal Generator3 Power Supply Options: External DC 24V via Terminal / USB-C / Built-in Lithium Battery (Battery-Equipped Model)Battery Type: Built-in 3.7V 1500mAh Lithium BatteryInterface: Type C PortDisplay: 2-inch TFT Color Screen (320×240 pixels)Display Interface: Switchable Chinese/English interfaceKnob: EC11 Digital Encoder Knob (20-step resolution per revolution, with push button)Terminal Plug Specification: 15EDGK3.81 (9P)Operating Environment: 0-40°C, Relative Humidity Application Scenarios: Industrial control DC analog signal debugging, electrical equipment installation and maintenance, PWM motor speed control, etc.Voltage Output Range: ±12V (Maximum 20mA under load, with short-circuit protection)Voltage Measurement Range: ±50VCurrent Output Range: 0-24mA (Maximum sampling resistance 500Ω, short-circuit protected)Current Measurement Range: ±50mAOutput Adjustment Range: Freely configurable (e.g., 0-20mA/4-20mA/0-10V/0-5V), with engineering display values user-definablePWM Pulse Square Wave Output: Frequency adjustable 1-150kHz, duty cycle adjustable 0-100% (high level fixed at 5V, drive current (Note: This PWM output is not suitable for 12V or 24V systems, as 5V is considered a low level for them.)Power Supply Specifications: 3 charging methods available—mobile phone charger, power bank, or external 24V DC input.1. External terminal power supply: DC 24V ±4V, 2W (non-charging mode)/5W (charging mode)2. External USB-C input: 5V, 0.4A (no charging)/1A (charging)3. (Battery-equipped model) Built-in 3.7V lithium battery, max charging current 0.8A. Battery indicator turns green and charging stops automatically when full. Typically takes over 6 hours to charge. Fully charged battery provides 1-5 hours of use depending on output load.Charging Status Indicators:1. When powered off and connected to Type-C charging, the charging indicator below turns red; turns green when fully charged.2. When powered on and connected to Type-C charging, the charging indicator below turns red. The battery icon in the upper-right corner of the screen displays green and cycles through increasing battery bars (regardless of remaining charge before charging, it starts green). When fully charged, the charging indicator below turns green, and the battery icon in the top-right corner of the screen remains solid green. When the Type-C charging cable is disconnected, the battery icon in the top-right corner of the screen displays white.Precautions:1. Turn off the power before connecting the cable.2. Exceeding the specified technical parameters may cause abnormal operation or damage to this instrument.Package include:Handheld PWM Pulse Signal Generator x1Flathead screwdriver x1USB charging cable x1Alligator clip test leads x4
