100% Kuoyuh 88 Series 5A 10A 15A 20A 25A 30A DC Automatic Reset Thermal Overload Protector Switch Circuit Breaker For Motors

Product Description KUOYUH 88 series 10A Manual Reset Thermal Overload protector switch with straight PIN Metal Nut Mini Circuit BreakerTechnical dataCurrent rating range:3~30AInput voltage rating :125/250VAC; 32/50VDCInterrupting Capacity : 125/250VAC x 1,000A(UL 1077)Typical life : 1,000 operations at 200% overloadInsulation co-ordination:Rated impulse withstand voltage 2.5kVDielectric Strength:> 1.500VAC/min.Insulation Resistance:>100MOHM (DC 500V)Degree of protection:Terminal area IP00, operating area IP40Mechanical/Environmental DataOperating Ambient Temperature: -10℃ to +60℃ Mounting: Various options. See Ordering Information and drawings Termination: 250''(6.35mm)quick connects or solder terminalsCalibration(at25℃)100% of Rated Current: Hold , No Trip 150% ofRated Current: Trip Within 1 Hour200% of Rated Current: 5-30 sec Trip 300% of Rated Current: 1.5-5.0 sec Trip ApprovalApproval & File No                      Rated current                   Rated voltageCUL UL E155159                           3-30A                             125/250VAC; 50VDCTUV SUD B15 09 58611 007          3-20A                            125/250VAC; 32VDCVDE 40036160                               3-16A                             125/250VACCSA 102199                                   3-16A                             250VACIEC  60934                                      3-20A                            250VACTypical applicationsTarnsforms, Motors, Battery chargers, Power supplies, appliances, extra low voltage systems, machinery
