8K 4x2 HDMI Matrix 3D ARC HDR10 Video Switch Screen Splitter Converter with 4x1 Audio Extractor 4 in 2 Out Dual Display

8K HDR HDMI True Matrix 4x2 Upgrade with 4x1 Audio Extractor Note: 4X1 audio extraction mode (.Long Press the MODE key (A key),and the product can switch between 4X2 matrix and 4X1 audio extraction modes. When in 4X1 audio extraction mode,the four input channel indicators IN1-IN4 will all be lit. At the same time, the output A port only outputs audio signals. When a professional audio device(such as power amplifier/ echo wall,etc.)needs to be connected, It is recommended to connect the audio equipment to the OUT A port and switch to 4X1 audio extraction mode to obtain the best compatibility and sound quality. SPECIFICATIONS: Brand new and high quality,upgraded with 4x1 audio extractor,has solved the audio problem Input ports HDMI x 4 Output ports HDM x 2,RCAX2,Optical X1 Video format 480P/720P/1080P/2160P@24/25/30/50/60/100/120Hz Up to 4320P@50/60Hz(YCC420), Support HDR/Dolby Vision Deep color 8/10/12/16Bit@2160P 8/10bit@4320P Audio format Dolby HD/DTS HD/Dolby Atoms/Dolby AC3/DTS/LPCM Etc. Transmission bandwidth: 1GHz Max. Transmission rate: 40Gbps Max. IR distance ≤5m Input cable length 4320P/AWG 26 ≤2m;2160P/AWG 26 ≤5m;1080P/AWG 26 ≤10m Output cable length 4320P/AWG 26 ≤2m;2160P/AWG 26 ≤5m;1080P/AWG 26 ≤12m Power adapter specification AC 100~240V/ DC 12V/1A Max working current 300mA Working temperature range -5 ~ +40℃ Working humidity range 5 to 85%RH(No Condensation) Storage temperature -15 to 55℃ Storage humidity 5 ~95%RH(No Condensation) Size approx. 205x75x30 (mm) Package Content: 1PCS 8K 4x2 HDMI Matrix 1PCS Manual 1PCS Remote Controller without battery 1PCS Power Adaptor No retail box and other accessories,if any need,pls contact us before purchase. Matters needing attention: 1.Please use standard HDMI cable and connect the cable before powering the equipment. 2.Please preferentially connect 8K TV to OUTB. OUTA outputs 8K@60 or 4K@120 resolution only in split mode (In this mode, OUTA and OUTB select the same input source). The maximum output resolution is 8K@30 or 4K@60 in other modes. 3.The product has power off memory function. The setting state of the output channel is recorded and saved. After the power is off, the saved data will be automatically retrieved for configuration. 4.The AUDIO OUT is a set of multiplexed ports that allow you to select HDMI OUTA/B sounds by using the "A-B" key. 5.The Audio EDID mode selection is also available for multiplexed. When the audio source selects channel A, the audio EDID mode is valid for channel A. So when the audio source selects channel B, the audio EDID mode is valid for channel B. 6. Analog audio can only be output when the audio format is LPCM, so it is recommended to choose the EDID mode in 2CH mode when using analog audio output. 7. If you want to use ARC or CEC, you must connect the TV to the OUTA port. Before using ARC, make sure your TV HDMI port supports ARC and the ARC have been turned on. 8.Simple Downscaler Ov
