100-240V RF 433Mhz Light Switch Remote Control 1/2/3 Gang Panel Wall Switch Wireless ON OFF Switch Interruptor for LED Lighting

Specification:controller (Receiver):Working voltage: AC85-240V 60HZ/50HZWorking frequency: 433MHZPower consumption in standby mode: Load power: Receiving sensitivity: -108dBMWorking way:wireless controlCoding way: learning codeModulation: ASKWorking temperature: -10C~+70"CSize: 47.44222.8 (mm)Wireless Wall Switch:Working voltage: DC3.0Vworking frequency:433MHZPower consumption in standby mode:Transmitter power: Working way: wireless controlCoding way: EV1527 learning codeModulation: ASKWorking temperature:-10"C~+70CSize: 8686 15mm Working principle of RF433 circuit breaker:1. Press the learning button (433 circuit breaker) once, then press the remote control button that comes with it again, and the indicator light will flash twice (learning switch).2. Press the learning button (433 circuit breaker) twice in a row, and then press the button on the remote control that needs to be equipped. The indicator light will flash twice (learning on).3. Press the learning button (433 circuit breaker) three times in a row, and then press the remote control button to be equipped. The indicator light will flash twice (learning off).4. Press the learning button (433 circuit breaker) continuously for 6 times, and the light will flash 3 times (power on start function), and it will default to the on state when powered on.5. Press the learning button (433 circuit breaker) continuously for 7 times, and the light will flash 3 times (the function will not be activated when powered on).6. Press and hold the learning button (433 circuit breaker) for more than 5 seconds, the indicator light will flash twice (cancel all remote control codes). Note:The relay controller is RF Receivers, the wall switch is RF only. Wall switch itself cannot control lights on off. It needs to work with rf receiver together.Feature:1.Multi switches can control different receivers.Save energy,avoid darkness.2.Working with all kinds of Lights and Ceiling Fan.LED,CFL,Fluorescent lamp can load 300W,other can load 2500w.3.It is a 86 wall panel that can be stuck onto anywhere. It is a learning code transmitter EV1527 IC Chip. It can be learned into most of the learning code receiver.
