100-220V RF 433Mhz Light Switch Mini 10A Relay Receiver 1/2/3 Gang Wall Panel Switch Remote Control Home LED Light Interruptor

Specification: Controller (Receiver): Working voltage: AC85-240V 60HZ/50HZ Working frequency: 433MHZ Power consumption in standby mode: <0.3W Load power: <1100W Receiving sensitivity: -108dBM Working way:wireless control Coding way: learning code Modulation: ASK Working temperature: -10C~+70"C Size: 47.44222.8 (mm) Wireless Wall Switch: Working voltage: DC3.0V working frequency:433MHZ Power consumption in standby mode:<1uA Transmitter power: <10mW Working way: wireless control Coding way: EV1527 learning code Modulation: ASK Working temperature:-10"C~+70C Size: 8686 15mm

Working principle of RF433 circuit breaker:

1. Press the learning button (433 circuit breaker) once, then press the remote control button that comes with it again, and the indicator light will flash twice (learning switch). 2. Press the learning button (433 circuit breaker) twice in a row, and then press the button on the remote control that needs to be equipped. The indicator light will flash twice (learning on). 3. Press the learning button (433 circuit breaker) three times in a row, and then press the remote control button to be equipped. The indicator light will flash twice (learning off). 4. Press the learning button (433 circuit breaker) continuously for 6 times, and the light will flash 3 times (power on start function), and it will default to the on state when powered on. 5. Press the learning button (433 circuit breaker) continuously for 7 times, and the light will flash 3 times (the function will not be activated when powered on). 6. Press and hold the learning button (433 circuit breaker) for more than 5 seconds, the indicator light will flash twice (cancel all remote control codes).

Note: The relay controller is RF Receivers, the wall switch is RF only. Wall switch itself cannot control lights on off. It needs to work with rf receiver together.

Feature: 1.Multi switches can control different receivers.Save energy,avoid darkness. 2.Working with all kinds of Lights and Ceiling Fan.LED,CFL,Fluorescent lamp can load 300W,other can load 2500w. 3.It is a 86 wall panel that can be stuck onto anywhere. It is a learning code transmitter EV1527 IC Chip. It can be learned into most of the learning code receiver.
