XMSJ | ZM-7205A 310V High Voltage High Power DC Brushless Motor Driver 220V AC Max 5A 1100W BLDC With Handheld Intelligent Setting Unit

ZM-7205A 310V High Voltage High Power DC Brushless Motor Driver 220V AC Max 5A 1100W BLDC With Handheld Intelligent Setting UnitDescription:ZM-7205A brushless DC motor driver is the latest product introduced by our company. It is aimed at high-tech products in the field of medium power motor drive. This product uses a large-scale integrated circuit to replace the original hardware design, with higher anti-jamming and fast response performance. This product is suitable for driving input current below 5A, power supply voltage in AC70V~230V (panel nominal AC80V~220V) Or three-phase brushless DC motor without Hall, and has the characteristics of low temperature when working with large current.Application:Products used in a series of knitting equipment, medical equipment, food packaging machinery, electric tools, etc. Electrical Automation Control.Feature:1.External speed display board, display speed; can also be connected to the computer, used to set the drive parameters; 2.Double closed-loop current speed design, high torque at low speed, stable operation; 3.High torque and high speed output, the maximum speed of 20000rpm/min; (according to the user's motor may be) 4.Speed control mode: External PWM speed control or external potentiometer speed adjustment; 5.EN (enable), DIR (direction), X1 (brake) signal control end; 6.Can output speed pulse FG, (photoelectric isolation, gate output); 7.Can output alarm signal ALM for user detection (photoelectric isolation, gate output); 8.With overcurrent, overvoltage, undervoltage, fan control, Hall sensor phase error, motor stall protection and other protection functions 9.70-220VAC input, 5A current, could drive brushless dc motor with power below the 1100WMajor Function:This product can realize the following functions: (Standard factory default setting is square wave Hall open loop mode) 1. Square Wave has Hall Speed Open Loop Operation 2. Square wave has Hall speed closed loop operation 3. Square wave without Hall speed open loop operation 4. Square wave without Hall speed closed loop operation 5. Constant torque open-loop mode operation (Long-term overload operation is strictly prohibited) 6. Constant Torque Closed-Loop Mode Operation (Long-term overload operation is prohibited) The above functions can be set according to the PC software or handheld debugger provided by our company.Note:When there is no Hall operation, there is no direction control function;
