CG | CG Dual Digital Display Adjustable Over Under Voltage Current Protector 40A 60A 110V 220V CG2-VA5 DIN Rail Mounting Protection

Product CharacteristicsOver/Under Voltage ProtectionOver Current ProtectionLarge LED Digital DisplayAdjustable Parameter SettingsMicrocontroller-based Intelligent ControlDin-rail Mounting for Easy InstallationPackage Contents1× Voltage Current Protector1×35mm DIN Rail2×DIN Rail Sleeve2×ScrewNOTESUnder DC power, only the voltage is displayed, and current is not shown. In parameter P15, there are three displaymodes: Mode 1 (Standard) shows parameters P1–P19; Mode 2 (Manual) allows the user to press the ↑ or ↓ buttonto manually view voltage (-U-), power (-P-), current (-A-), and frequency (-H-); Mode 3 (Automatic) will automaticallydisplay voltage (-U-), power (-P-), current (-A-), and frequency (-H-) in sequence. For parameter P19 (Password),the initial password is set to 112. After changing the lock parameter, the password may be reset. To unlock, theparameter must be restored to the initial password (112).
