GOLDIX R160 Ultra Light Road Bicycle Hub 24H 270g 72T Ratchet HG/XDR Center Lock Disc Brake 10-13 Speed Steel Spoke Compatible

GOLDIX originates from China's largest bicycle hub manufacturer. We offer a comprehensive range of models and specifications, backed by strong technical expertise.We invite you to purchase our products. We also provide customization services for non-standard designs.Please feel free to contact us if you have any questions!Brand: GOLDIXModel: Road Bike R160 SeriesFreehub Body Type: HG / XDRFront Hub Spacing: 100x9mm / 100x12mmRear Hub Spacing: 135x10mm / 142x12mmBrake Type: Center Lock Disc BrakeSpokes: Steel spokes, 24 holesBearing Brand: TPI (Taiwan)Front Hub Bearings: Hub shell 6803 x 2 (100x12mm)Rear Hub Bearings: Hub shell 15267 x 1 & 6902 x 1 / Freehub body 6802 x 2Maximum Single Spoke Tension: 2500NWater/Dust Resistance Rating: IP42–IP53Ratchet System: All-new 72T ratchetWeight: Please refer to product images (a variance of ±10g may occur between batches; placing an order constitutes acceptance of this term)Freehub Type Notes: (Important: Please verify your drivetrain system and required freehub model before purchasing! Otherwise, installation will not be possible.)HG: Compatible with Shimano 10–12 speedXDR: Compatible with SRAM 10–12 speedProduct Features: The all-new GOLDIX R160 series features comprehensive upgrades and optimizations to the hub shell, bearings, ratchet engagement mechanism, engagement surface area, and surface coating process,aiming to significantly enhance product reliability, durability, and the user experience. While maintaining the original weight, the conical ratchet design eliminates the need for a separate ring gear by integrating it directly with the ratchet mechanism, allowing pedaling force to be transmitted straight to the hub for improved efficiency. This integrated design features a larger diameter than traditional ratchets, accommodating a higher tooth count; for the same number of teeth, the load-bearing surface area increases by over 45%, enabling the system to withstand greater torque than traditional ratchets while remaining compatible with standard ratchet hubs.
