RCXAZ RC 550 Brushed Motor and 60A ESC Combo 10T/12T/21T/29T/35T/55T for 1/10 1/12 RC Crawler Truck Buggy Witoys 124017

Remarks: "T" mean the number of turns. 10T 12T 21T motors fit high speed RC Car. 29T 35T 55Tmotors fit large torque RC Crawler.Features:550 Brushed Waterproof Motor is a budget motor built for messy, dirty, off road action.This powerful 550 motor has a 30% longer armature than a standard 540 size motor for extreme monster torque.Heat-resistant motor with built-in cooling fan, allows fast speeds, long runtime, and long lifetime.High strength magnets ensure maximum performance.1/8th inch shaft diameter,ball bearing on output side.Bullet plugs is easy connection with no soldering needed.The four models that are available to choose from are 12T/21T/29T/35T/55T.Specifications:Motor Diameter: 36mmMotor Shaft Length: 16mm(12T) 11mm(21T 29T 35T 55T)Shaft Diameter: 3.17mmUse voltage: 7.4-11.1VWeight: about 230gSuit For: RC Car / BoatESC:Product Parameters:1: Continuous/Peak Current: 60/320A.2: Battery Cells: 4-9 Cells NiMH, 2-3S Lipo. Built-in BEC BEC Output: 6V/2A.3: Current Parameters: Forward 320A, Reverse 160A, Braking 270A, Continuous Current: 60A.4: Supported Motor Types: Brushed motors, suitable for 380/390/540/550 series size brushed motors.5: Main Vehicle Types: 1/16/1/12/1:10 electric touring cars / electric buggies / trucks / big foot cars / crawler vehicles.6.Three-mode regulationMode 1(jumper cap inserted into the left two-pin header F/B indicates): This mode provides reverse functionality and is usually used for training. The "forward/reverse with brake" mode uses a double-click reverse method. That is, when the throttle trigger is first pushed into the reverse area, the motor only brakes and does not produce a reverse action. When the throttle trigger is returned to the neutral area and pushed into the reverse area for the second time, the reverse action is generated.Mode 2(jumper cap inserted into the right two-pin header B/R indicates): In this mode, the vehicle can only move forward and brake, but cannot reverse. This mode is usually used for racing.Mode 3(no jumper cap inserted): When set to this mode, the motor directly reverses. Pushing the throttle trigger forward or backward always results in braking operation. (This mode consumes more power)
