diymore | ESP32-C5-N16R8 WiFi 6 Bluetooth BLE IoT MINI Core Development Board 2.4G CH340C Type C Supports External Antenna Electronic Kit

Product Features:Dual-band WiFi6 high-speed networking, compatible with 802.11ax/b/g/n, with a maximum transmission rate of 150Mbps.2. Multi-protocol wireless integration, suitable for smart home gateway development.3. RISC-V high-performance core, supporting clock frequencies up to 240 MHz with strong computational capabilities.4. Supporting 2Mbps helps in building IoT devices with broader coverage and stronger RF performance.5. Industrial-grade stable operation across a wide temperature range, suitable for industrial and outdoor IoT projects.Product IntroductionThe ESP32-C5-N16R8 MINI is a high-performance IoT development core board featuring the ESP32-C5 chip. It supports dual-band WiFi6 (2.4GHz/5GHz), operates on a RISC-V single-core architecture with a maximum frequency of 240MHz, and is equipped with 16MB Flash + 8MB PSRAM. With robust RF performance, it excels in both high-speed transmission and long-range communication. The compact MINI form factor is ideal for rapid prototyping and product solution validation. Additionally, it supports 2 Mbps PHY to enhance transmission speed and data throughput, facilitating the development of IoT devices with broader coverage and superior RF performance.Product Parameters:Equipped with an ESP32-C5 chip, featuring a RISC-V 32-bit single-core processor supporting clock frequencies up to 240 MHz• ROM：320 KB• HP SRAM：384 KB• LP SRAM：16 KB• Flash:16 MB(Quad SPI)• PSRAM:8 MB(Quad SPI)Wi-Fi：• Operates in dual bands of 2.4 GHz and 5 GHz, with 1T1R configuration• Working channel center frequency range: 2412 ~ 2484 MHz, 5160 ~ 5885 MHz• Compatible with IEEE 802.11ax protocol• Fully compatible with IEEE 802.11b/g/n protocols:- Supports 20 MHz and 40 MHz bandwidth- Data rate up to 150 MbpsWireless Multimedia (WMM)Frame aggregation (TX/RX A-MPDU, TX/RX A-MSDU)- Immediate Block ACKBluetooth:• Low Energy Bluetooth (Bluetooth LE): Bluetooth 6.0• Bluetooth mesh 1.1• High-power mode (20 dBm transmit power)Working conditions:• Operating voltage/power supply voltage: 3.0 ~ 3.6 V• Operating temperature: -40 to 85 °CProduct dimensions: 36.5mm x 33mmApplication scenarios: Smart gateways, smart home central controls, wireless sensors, IoT nodes, multi-protocol bridging devices, product prototype development, etc.Product includes:1X Development Board2X pin header
