Miniware | Miniware Smart Digital Power Supply Module Programmable Linear Control Modules 4.2-30V MDP-M01/P906/L1060

Description:MDP (Mini Digital Power System) is a system of programmable linear DC power supply based on modular design, capable of connecting up to 6 different modules for use as needed.For its novel, beautiful and trendy design, MDP won a Red Dot in the Red Dot Award: Product Design 2020.MDP-P906 is the second digital power supply module of MDP series, following MDP-P905. MDP-P906 has a built-in cooling fan, and a maximum output power up to 300W, which meets a wider range of testing needs and application scenarios. Through 2.4G wireless communication, it can be connected to MDP-M01 SmartDigital Monitor module to realize the free combination of multiple channels of 300W per channel, and it is alsostackable with MDP-XP set (MDP-M01+MDP-P905) to form a multiple modular portable Mini digital power system.MDP-L1060continues the stackable design of MDP series, small in size and portable as a whole. The built-in 650mAh battery can meet a short-term emergency load test cordless. The main body of the load module adopts a CNC aluminum alloy frame with built-in high-efficiency brass heat sinks and high-speed cooling fans, which can automatically adjust the wind speed for heat dissipation according to the load consumption. The hollow decorative pieces on the front and rear of the module can maximize the air intake and ensure the heat dissipation speed. The load input port adopts a 4mm three-purpose gold-plated standard port, and is equipped with an XT30 input port for remote compensation, which can complete a more accurate load test.Product Features: MDP-M01lModular design with MDP-M01 Display Control Module support up to 6 channels output when more power supply mode connected to achieve multichannel free combination at the power of 90W per channell2.8 inch TFT screen display the voltage-current waveform and output parameter in real time with dual thumb wheels and 90-degree scrolling screen which is super convenient to monitor and operationlDC 4.2-30V 100mA-6A wide range input and max. 30V 5A 90W CC CV adjustable output per channel with input over-voltage protection, under-voltage protection, anti-reverse connection protection and output anti-backflow protection, over temperature protection, over current protectionlHigh-speed transient response and over current protection, as fast as 4uS, Extremely low load regulation and intelligent line loss compensationlSupport positive & negative pressure, series pressurization, parallel current sharing, free combination of collaborative load, and intelligent power allocationlSupport data record with max. 7Mb recording storage and hours recording timelhigh cost-effective programmable linear DC power supply, featuring indicators, stability, reliability and distinct user interface comparable with professional linear DC power supplyProduct Features: MDP-P906l 2.4G wireless connection, supportingwireless connection to Display Control modulel DC wide voltage input between 4.2V- 30Vl Support Max 20V QC/PD inputl 95% High efficiency programmable linear output, max 300Wpower outputl Built-in low noise & high-speed cooling fanl Ultra high-speed transient response& ultra low ripple and noisel Extremely low load regulationrate with smart linear loss compensationl Support Boost mode, highly reliable for various electrical devicesl Supportmultiplein-series and in-parallel connectionto output higher voltagelSafety Protections:input over-voltage, under-voltage, reverse connectionprotection, output over-current,backflowprotection and overtemperatureprotectionl Support firmware upgradeProduct Features: MDP-L1060l Stackable design of MDP series, miniaturized, convenient and easy to use;l 2.4G wireless communication, realizing complex remote control and advanced functions through MDP display control module;l 4 Working modes: constant current (CC), constant voltage (CV),constant resistance (CR) & constant power (CP);l 5 Advanced functions: battery (capacity) test, internal resistance test, factory test, dynamic test & over-current protection test;l 6 Major intelligent safety protections: over-voltage (OVP), under-voltage (UVP), over-current (OCP), over-power (OPP), over-temperature (OTP) & anti-reverse protection;l Intelligent fan/wind speed control, efficient heat dissipation, energy saving;l Better accuracy with 4mm three-purpose gold-plated standard input port, XT30 remote compensation input port;l Support programmable loading test.Applications:MDP-M01-Universal tests and teaching experiments in R&D laboratory-Maintenance of cellphones, laptops and other digital products-Power supply testing and data logger of RF and microwave circuits or modules-Supply purified power for high-accuracy digital-analog hybrid circuits and Hi-Fi audio devices-Property verification and fault diagnosis of devices and circuits-Quality control and quality inspection-Emergency power supply for model airplanes and vehiclesApplications:MDP-P906ü Universal tests and teaching experiments in R&D laboratoryü Maintenance of cellphones, laptops and other digital devicesü Power supply testing and data logger of RF, microwave circuits and other modulesü Provide purified power for high-accuracy digital-analog hybrid circuits and Hi-Fi audio devicesü Performance verification and fault diagnosis of devices and circuitsü Quality control and quality inspectionü Emergency power supply for RC models, vehiclesand digital devicesApplications:MDP-L10601.Constant current working mode (CC): The load always consumes a constant current regardless of how the input voltage changes.2.Constant voltage working mode (CV): The load will consume enough current to keep the load input voltage constant at the set value.3.Constant resistance working mode (CR): The load is equivalent to a constant resistance, and the load input current will be adjusted with the change of the load input voltage4.Constant power working mode (CP): The load will consume a constant power, and the load input current will be linearly adjusted with the change of the load input voltage to ensure that the power consumption remains unchanged.Specifications：MDP-M01-Input Power: DC4.2-30V(2.7V after Start-up),100mA-6A-Output: 30V 5A 90W(Max. per channel-Adjustment Rate: -Ripple and Noise: 250uVrms/3mVpp-Transient Response Time: ≤4uS-Line Loss Compensation Range: 5mR-100mR-Date Record: 7Mb Max. Storage and 24 hours Max. Time-Protection Support:Input:over-voltage, under-voltage, anti-reverseOutput: anti-backflow, over temperatureSpecifications：MDP-P906ModeMDP-P906InputDC4.2V-30V 14A (Max)QC3.0/PD2.0 20V 5A (Max)Output0-30V 0-10A 300W (Max)Output resolution10mV, 2mA; up to 1mV, 1mA via Display Control moduleOutput accuracy0.03%+5mV, 0.05%+2mAAdjustment rateLoad adjustment rate Power adjustment rate Ripple and noise＜250uVrms, 3mVpp; ＜2mArmsTransient response＜4uSSafety ProtectionsInput over-voltage, under-voltage, reverse connection protection, output over current, back-flow protection and over temperature protectionOthersAutomatically shut down and enter micro-power modeSupport USB firmware upgradeSpecificationSize(not include rubber feet)Weight112mm66mm20mm181gSpecifications：MDP-L1060Product ModelMDP-L1060Power inputDC 5V 2ABattery capacity650mAhInput InterfaceUSB TYPE-CMaximum load input voltage60VMaximum load input current10AMaximum load input power100WSafety protectionsOver voltage protection (OVP), under voltage protection (UVP), over current protection (OCP), over power protection (OPP), over temperature protection (OTP), anti-reverse protectionSize11266.535 (mm)Weight330gMDP-P906 Package Included:- 1 x MDP-P906 Digital Power Supply- 2 x Output Cable- 1 x user ManualMDP-M01 Package Included:1X MDP-M01 Display Control Model1X English Manual1 x user manualMDP-L1060 Package Included:- 1 x MDP-L1060- 1 x User Manual- 1 x XT30 Female Connector- 2 x Input CableMDP-M01+ MDP-P906 Package Included:- 1 x MDP-P906 Digital Power Supply- 1 x MDP-M01 Display Control Model- 2 x Output Cable- 1 x user Manual
