EKLEVA 4 Inch Car DVR Camera 4K&1080P Video Recorder WIFI ADAS Speed Dashcam Dash Cam Car Registrar Super Night Vision

EKLEVA 4 Inch Car DVR Camera 4K&1080P Video Recorder WIFI Speed GPS Dashcam Dash Cam Car Registrar Super Night Vision

Normally we send the ACC power cable as the power cable(support 24 hours parking monitor). but if you need a car charger power cable, please note us before your place an order. Thank you.

Specification

CPU:Allwinner 536
Display: 4 Inch
Memory card: Class 10 TF card(8-128GB)
Video resolution: 3840×2160(4K)
GPS :Support(select)
WIFI :Support(Standard configuration)
Camera Lens: 4K Sony IMX 415
Time-Lapse : Off/ 1S/ 2S/ 3S
Parking Guard: Off/ Low/ Middle/ High
Screen Saver: Support to set the time when the screen turns off automatically
Frequency: 50HZ/ 60HZ
Key sound: ON/ OFF
Boot sound: ON/ OFF
Speaker Sound: Mute/ Low/ Middle/ High
G-sensor: Off/ Low/ Middle/ High 3 options of sensitivity
Lens: 1200M pixels,170 degree HD wide angle
Seamless video: No interrupt video
Loop video: Optional 1/2/3/5 min, new file auto overwrites old file when the card is full.
Aperture: F2.0
Button Sound: Turn on/off Date/
Time: Support 2 split-view displays simultaneously: Support
Battery: Built-in lithium-polymer battery
Car USB power: 5V
Working temperature:-20℃ to 70℃
Storage temperature:-30℃ to 80℃
Installation type: Rearview mirror Camera
Application: 4K Camera, Streaming media rearview, Excellent night vision, Reversing video, 24h Parking monitor, Collision sensor, Front and rear dual video, Loop recording, Adjustable view angle, Special mounting holder

170° Ultra Wide Angle

170° ultra-wide-angle camera provides crystal image without any delay and reduces blind spots, comfortably monitors 3 lanes, reduces blind spots, captures license plates, road signs, and other critical details on the road.

4K UHD Display High sensitivity 4 Inch 4K 3840*2160P UHD IPS touch screen, made of high-quality material, advanced IPS technology, and high color saturation technology that allows the screen display clearer.

Sony 415 Make Recordings Sharper and Better The new high-definition glass lens module and upgraded zoom lens make the recorder's picture free from blur and distortion under long-term working conditions. The powerful lens is as good in harsh conditions.

Wide Dynamic Range

WDR significantly improves image clarity by reducing noise and adjusting exposure balance, ensure clear recording in bright and dark light and capture high definition, realistic images.

HD Night Vision Use night vision lens without supplement light, smart chip all-glass lens, good light transmission, sensory sensitivity, and clear imaging. The license plate is still clearly visible in any environment.

GPS Track GPS accurately records your driving data. Dedicated player, playback display is more detailed, including time, speed(km/h, mph), and coordinates.

Built-in Wifi & App APP intelligently connects to retrieve accident videos in real-time. View real-time video, playback video, or download video through the mobile APP picture-in-picture.

Loop Recording & Emergency Recording New footage will automatically overwrite older footage when the memory card reaches full capacity, seamlessly recycle the storage space. In an emergency such as emergency braking or collision, it will automatically take pictures and keep the video, and the emergency video will not be overwritten.

Real-time Reversing View When reverse gear is engaged, the rearview mirror screen automatically switches the reversing image and displays the auxiliary line, make blind spots all visible when reversing and warehousing.

24-Hour Parking Surveillance Keep monitoring when you are away. G-sensor can detect sudden shakes or collisions while your car is stationary, and will automatically capture the moment of detecting collision after parking. Attention: It should be connected by a hardware kit.

HIGH-ENDURANCE Micro SD Card Max 100MB/S Read TF Card only for Pongki Dash Cam

The memory card may become damaged or deteriorated after repeated cycles of overwriting, and this may affect its ability to save video and image files. If this occurs, immediately replace it with a new memory card. *HIGH-ENDURANCE SD Card, max up to 100MB/s read, 45MB/s write

Warm and Important Tip

The device needs to connect to the car power will work well, if you charge at home with another charger the screen will flash or the device will damage because of unstable voltage and current.

Q: How to connect the power cable?

A:1. Suggest search the information from the internet to find your car fuse box, open the box with the plastic pry tool
2. Use the electro probe, find the ACC power fuse and Constant power fuse, we recommend you use reading lamps, headlights, tail lamps, turn signals, power windows fuse to supply the Constant power (if they are constant power fuse)
3. ACC power: When you plug your car key then turn it to ACC, the power will work. if you urn your car Key to Lock or unplug your can, the power will be off. Connect the red wire (ACC) with the ACC power fuse.
4. Constant power: plug or unplug your car key, the power is uninterrupted. Connect the yellow wire (B) with the Constant Power fuse. For some cars, you have to cut the wires, refit them then connect them with the car fuses. Then plug the fuse to where it is
5. The GND wire (black) to connect it with steel plate or screw

Note:

1. Our products include rearview cameras. If you want to use your own rear camera, it may not work properly. We recommend using the original camera in the packaging.
2. This product should be connected to the power supply through the charger in the package to ensure that there is enough voltage and current to support the normal operation of this product. If you only use the USB connection, the recorder will not turn on.
3. The shape of the charger and the rear camera may be different, but the functions are the same.
